Linear Motion Drying Shaker
The S3S adjustable drying shaker uses linear motion to pull liquid out of the waste stream and return it to your active system for reuse. The Axiom AXL recovers lost circulation material from a triple-deck layout.
Shaker specifications
| Model | Max flow (gpm) | Screens | Screening area (in²) | G-force | Conveyance (in/s) | Dimensions (L × W × H) | Weight (lb) | Electrical | Enquire |
|---|---|---|---|---|---|---|---|---|---|
| S3S Adjustable Drying Shaker | 500 | 3 cascading panels, API 50 to 400 mesh | 3,816 | 7.5 G at discharge | 6.5 | 104 × 81 × 75 in | 5,200 | 480 VAC, 4.4 A full load | Enquire about the S3S Adjustable Drying Shaker |
| Axiom AXL shaker (S3S-LCM Recovery Unit) | 20 to 150 per unit | Triple deck, series or parallel, bladder-tensioned screens | Not listed | 4 to 5 G per unit | Not listed | Riser skid 20 × 8 × 8 ft | 8,300 per unit | 480 VAC, 60 Hz, 3 phase, 14 A | Enquire about the Axiom AXL shaker (S3S-LCM Recovery Unit) |
Drying shaker deck height adjusts from 37 in to 62 in. AXL units run in triple or quadruple sets with independent VFD-controlled pumps. Data sheets: Adjustable Drying Shaker and S3S-LCM Recovery Unit.
Mud conditioner specifications
| Model | Desander | Desilter | Feed per cone (gpm) | Feed pressure | Cone assembly weight (lb) | Mounting | Electrical | Enquire |
|---|---|---|---|---|---|---|---|---|
| S3S Mud Conditioner | 2 in-line cones, 10 in | 12-cone rotary, 4 in | 500 per desander cone, 50 per desilter cone | 3.9 × mud weight (32.5 psi on fresh water) | 1,500 added | On an S3S shaker or an adjustable stand | 480 VAC, 4.4 A full load (shaker) | Enquire about the S3S Mud Conditioner |
Source: S3S Mud Conditioner data sheet.
Talk to an S3S screening expert.
S3S selects the shaker and screens for your fluid, throughput, and target cut point, integrating the screening stage with downstream equipment. Our technicians install, operate, and adjust the system throughout the job, guided by particle size analysis from the S3S lab.
